Widespan IBR Roll Forming Machine With Hydraulic Cutting, Panasonic PLC Control System

Name: Widespan IBR Roll Forming Machine With Hydraulic Cutting Panasonic PLC Control System
Brand: TECHWELL
Price: 1 USD

Cheap Widespan IBR Roll Forming Machine With Hydraulic Cutting, Panasonic PLC Control System for sale

Place of Origin : China

Brand Name : TECHWELL

Certification : CE

Model Number : TW-RWM

MOQ : 1 Set

Price : Contact Us

Packaging Details : Standard packing

Delivery Time : 55-65 working days

Payment Terms : 40% T/T in advance, 60% T/T before shipment

Supply Ability : 20 sets

Contact Now

Widespan IBR Roll Forming Machine With Hydraulic Cutting, Panasonic PLC Control System

Main Specifications of IBR Roll Forming Machine

Item	Widespan IBR Roll Forming Machine
Coil Material	Thickness	0.3-0.8mm
	Coil width	925mm or 940mm, Custom-made
	Yield Strength	250-350 Mpa
	Material	PPGI, Color Steel, GI.
Decoiler / Uncoiler	Decoiler Type	Manual or Hydraulic or Auto Type
	Coil Width	Max. 1250mm
	I.D	508-610mm
	O.D	Max. 1500mm
IBR Roll Forming Machine	Forming Stations	18 Stations ( Depend on Profiles )
	Roller material	45# steel, surface coated with 0.05mm hard chrome
	Diameter of shaft	76mm
	Shaft material	High grade 45# steel
	Drive type	Chain transmission
	Forming speed	0-15m/min
	Main power	5.5KW
Cutting	Cutting type	Hydraulic cutting
	Cutting Die Material	Cr12Mov steel, HRC58-62
	Cutting power	3KW
	CuttingTolerance	10m+/-1.5mm
	Encoder	OMRON Brand
Electrical control	PLC	PANASONIC Brand
	Inverter	YASKAWA Brand
	Touch screen	PANASONICE
	Operation type	Touch screen & Button
Hydraulic Station	Hydraulic station	Famous Chinese brand
Runout Table	Table type	Simple nonpower type
Runout Table	Function	To support the finished panels

Main Components of IBR Roll Forming Machine

Decoiler / Uncoiler	1 Unit
Feeding Guide	1 Unit
Widespan IBR Roll Forming Machine	1 Unit
Hydraulic Cutting Device	1 Unit
Hydraulic Station	1 Unit
PLC Computer Control Board	1 Unit
Runout Table	2 Units

Reference IBR Drawings

Widespan IBR Roll Forming Machine With Hydraulic Cutting, Panasonic PLC Control System

Applications

IBR Sheet, IBR Sheeting, Chromadeck IBR Roof Panel, IBR Roof Sheeting, Trapezoidal roof panel, trapezoidal sheet, trapezoidal roof metal, trapezoidal roofing, metal roof; steel roof; metal roof wall panel; steel roof wall panel; metal roofing sheet; steel roofing sheet; metal roof panel; steel roof panel; roof wall cladding; roof cladding; wall cladding

Our Advantage

Copra designing software
5-8 technicians every month specially do international installation and debugging
High Quality
Reasonable Price
Good after Service
1 Year Warranty
More Than 10 Years Experience

Widespan IBR Roll Forming Machine Pictures

Widespan IBR Roll Forming Machine With Hydraulic Cutting, Panasonic PLC Control System

Certificate

Widespan IBR Roll Forming Machine With Hydraulic Cutting, Panasonic PLC Control System
